"iwlwifi: invalid buffer destination" at boot. Why?

,

At boot, if I press Escape to disable plymouth (and display dmesg in the tty) I see an error message:

iwlwifi: invalid buffer destination

Any idea of how to ascertain why this appears, and how remediate it?

I’ve asked partly to provide a possible answer to the others asking this at Reddit - Dive into anything.

We need more information in order to understand the issue. Please post the result from running inxi -Fzxx in a terminal (as pre-formatted test using the </> button from the top line of the text entry panel).

  • Is this a fresh install or upgrade?
  • Are you dual booting? If so what other OS?

Some reports for this error mention lack of free mass storage space.

1 Like

@gnwiii:

cat -vbET '/etc/os-release' | Select-String 'CPE_NAME' has only ever returned cpe:/o:fedoraproject:fedora:40, but I’ve upgraded my packages many times. Usually every night, for approximately 4 months. Apologies for not being able to provide a better identifier - I’ve asked How to acquire specific release of installed OS? but not received an actionable answer yet.

Noteworthily, a few days ago, I endeavoured to install Windows 11 to attempt to diagnose whether Random Indefinite System Hang and crash - #10 by rokejulianlockhart was the fault of amdgpu drivers bundled in the kernel, or a fault with my hardware. I’d also been having trouble witn a network card’s Bluetooth 5.1 connection, which I’d noticed had been outputting a significant amount of iwlwifi errors in dmesg.

The first few times I installed Windows, I would immediately see a Startup Repair dialog on the bootloader to initiate chkdsk, and it would then BSOD and bootloop. After scouring the internet, I learnt that some PCIe network cards using Intel chips can cause significant problems with Windows. Indeed, removing my PCIe x2 BT 5.1 and Wi-Fi 6 card elimited 99% of the iwlwifi errors and allowed Windows to install without fault. I don’t use that card anymore, because although it might be significantly better at its job than my motherboard’s in-built one, it appears to introduce both visible and invisible problems across OSes.

I’ve installed Windows 11 Pro 24H1 or 24H2 (I’m on Release Preview). However, solely one iwlwifi error remains in dmesg when booting Fedora, so I’d like to diagnose that too, to ensure that I’ve no additional as-yet unknown problems with my build. Note that the chipset I’m using now is in-built to the motherboard, and consequently can solely be disabled on a hardware level from the UEFI’s GUI.

  1. inxi -Fzxx


    returns

  2. System:
      Kernel: 6.9.7-200.fc40.x86_64 arch: x86_64 bits: 64 compiler: gcc
        v: 2.41-37.fc40
      Desktop: KDE Plasma v: 6.1.1 tk: Qt v: N/A wm: kwin_wayland dm: SDDM
        Distro: Fedora Linux 40 (KDE Plasma)
    Machine:
      Type: Desktop System: ASRock product: X670E Taichi v: N/A
        serial: <superuser required>
      Mobo: ASRock model: X670E Taichi serial: <superuser required>
        UEFI: American Megatrends LLC. v: 1.21 date: 04/26/2023
    Battery:
      Device-1: hidpp_battery_0 model: Logitech Wireless Mouse MX Master 3
        serial: <filter> charge: 100% (should be ignored) status: discharging
    CPU:
      Info: 6-core model: AMD Ryzen 5 7600X bits: 64 type: MT MCP arch: Zen 4
        rev: 2 cache: L1: 384 KiB L2: 6 MiB L3: 32 MiB
      Speed (MHz): avg: 2255 high: 5246 min/max: 400/5453 cores: 1: 400 2: 400
        3: 4351 4: 5161 5: 400 6: 400 7: 400 8: 4360 9: 5246 10: 5147 11: 400
        12: 400 bogomips: 112809
      Flags: avx avx2 ht lm nx pae sse sse2 sse3 sse4_1 sse4_2 sse4a ssse3 svm
    Graphics:
      Device-1: AMD Navi 10 [Radeon RX 5600 OEM/5600 XT / 5700/5700 XT]
        vendor: XFX Pine driver: amdgpu v: kernel arch: RDNA-1 pcie: speed: 16 GT/s
        lanes: 16 ports: active: DP-1 empty: DP-2,DP-3,HDMI-A-1 bus-ID: 03:00.0
        chip-ID: 1002:731f
      Device-2: AMD Raphael driver: amdgpu v: kernel arch: RDNA-2 pcie:
        speed: 16 GT/s lanes: 16 ports: active: none empty: DP-4, DP-5, DP-6,
        HDMI-A-2, Writeback-1 bus-ID: 59:00.0 chip-ID: 1002:164e temp: 35.0 C
      Device-3: Logitech BRIO Ultra HD Webcam driver: snd-usb-audio,uvcvideo
        type: USB rev: 2.1 speed: 480 Mb/s lanes: 1 bus-ID: 3-3:4 chip-ID: 046d:085e
      Display: wayland server: Xwayland v: 24.1.0 compositor: kwin_wayland
        driver: N/A display-ID: 0
      Monitor-1: DP-1 res: 2560x1440 size: N/A
      API: EGL v: 1.5 platforms: device: 0 drv: radeonsi device: 1 drv: radeonsi
        device: 2 drv: swrast gbm: drv: radeonsi surfaceless: drv: radeonsi wayland:
        drv: radeonsi x11: drv: radeonsi
      API: OpenGL v: 4.6 compat-v: 4.5 vendor: amd mesa v: 24.1.2 glx-v: 1.4
        direct-render: yes renderer: AMD Radeon RX 5700 (radeonsi navi10 LLVM
        18.1.6 DRM 3.57 6.9.7-200.fc40.x86_64) device-ID: 1002:731f
        display-ID: :0.0
      API: Vulkan v: 1.3.283 surfaces: xcb,xlib,wayland device: 0
        type: discrete-gpu driver: N/A device-ID: 1002:731f device: 1
        type: integrated-gpu driver: N/A device-ID: 1002:164e device: 2 type: cpu
        driver: N/A device-ID: 10005:0000
    Audio:
      Device-1: AMD Navi 10 HDMI Audio driver: snd_hda_intel v: kernel pcie:
        speed: 16 GT/s lanes: 16 bus-ID: 03:00.1 chip-ID: 1002:ab38
      Device-2: AMD Rembrandt Radeon High Definition Audio driver: snd_hda_intel
        v: kernel pcie: speed: 16 GT/s lanes: 16 bus-ID: 59:00.1 chip-ID: 1002:1640
      Device-3: AMD Family 17h/19h HD Audio driver: N/A pcie: speed: 16 GT/s
        lanes: 16 bus-ID: 59:00.6 chip-ID: 1022:15e3
      Device-4: Logitech BRIO Ultra HD Webcam driver: snd-usb-audio,uvcvideo
        type: USB rev: 2.1 speed: 480 Mb/s lanes: 1 bus-ID: 3-3:4 chip-ID: 046d:085e
      Device-5: Generic USB Audio driver: hid-generic,snd-usb-audio,usbhid
        type: USB rev: 2.0 speed: 480 Mb/s lanes: 1 bus-ID: 5-8:3 chip-ID: 26ce:0a06
      Device-6: TONOR TC30 Audio Device driver: snd-usb-audio type: USB rev: 1.1
        speed: 12 Mb/s lanes: 1 bus-ID: 5-9.2:5 chip-ID: 5678:1234
      API: ALSA v: k6.9.7-200.fc40.x86_64 status: kernel-api
      Server-1: PipeWire v: 1.0.7 status: active with: 1: pipewire-pulse
        status: active 2: wireplumber status: active 3: pipewire-alsa type: plugin
        4: pw-jack type: plugin
    Network:
      Device-1: Intel Wi-Fi 6E AX210/AX1675 2x2 [Typhoon Peak]
        vendor: Rivet Networks Killer driver: iwlwifi v: kernel pcie: speed: 5 GT/s
        lanes: 1 bus-ID: 49:00.0 chip-ID: 8086:2725
      IF: wlp73s0 state: down mac: <filter>
      Device-2: Realtek Killer E3000 2.5GbE vendor: ASRock driver: r8169
        v: kernel pcie: speed: 5 GT/s lanes: 1 port: a000 bus-ID: 4a:00.0
        chip-ID: 10ec:3000
      IF: enp74s0 state: up speed: 100 Mbps duplex: full mac: <filter>
    Bluetooth:
      Device-1: Intel AX210 Bluetooth driver: btusb v: 0.8 type: USB rev: 2.0
        speed: 12 Mb/s lanes: 1 bus-ID: 5-7:2 chip-ID: 8087:0032
      Report: btmgmt ID: hci0 rfk-id: 0 state: up address: <filter> bt-v: 5.3
        lmp-v: 12
    Drives:
      Local Storage: total: 4.1 TiB used: 1.92 TiB (46.9%)
      ID-1: /dev/nvme0n1 vendor: SK Hynix model: PC401 HFS256GD9TNG-62A0A
        size: 238.47 GiB speed: 31.6 Gb/s lanes: 4 serial: <filter> temp: 30.9 C
      ID-2: /dev/nvme1n1 vendor: Addlink model: M.2 PCIE G4x4 NVMe
        size: 1.82 TiB speed: 63.2 Gb/s lanes: 4 serial: <filter> temp: 30.9 C
      ID-3: /dev/nvme2n1 vendor: Samsung model: SSD 980 PRO 250GB
        size: 232.89 GiB speed: 63.2 Gb/s lanes: 4 serial: <filter> temp: 32.9 C
      ID-4: /dev/nvme3n1 vendor: Addlink model: M.2 PCIE G4x4 NVMe
        size: 1.82 TiB speed: 63.2 Gb/s lanes: 4 serial: <filter> temp: 40.9 C
    Partition:
      ID-1: / size: 1.82 TiB used: 349.18 GiB (18.8%) fs: btrfs
        dev: /dev/nvme3n1p3
      ID-2: /boot size: 973.4 MiB used: 386.3 MiB (39.7%) fs: ext4
        dev: /dev/nvme3n1p2
      ID-3: /boot/efi size: 598.8 MiB used: 50 MiB (8.4%) fs: vfat
        dev: /dev/nvme3n1p1
      ID-4: /home size: 1.82 TiB used: 349.18 GiB (18.8%) fs: btrfs
        dev: /dev/nvme3n1p3
    Swap:
      ID-1: swap-1 type: zram size: 8 GiB used: 1.24 GiB (15.6%) priority: 100
        dev: /dev/zram0
    Sensors:
      System Temperatures: cpu: 46.2 C mobo: N/A
      Fan Speeds (rpm): N/A
      GPU: device: amdgpu temp: 36.0 C device: amdgpu temp: 39.0 C mem: 40.0 C
        fan: 3351
    Info:
      Memory: total: 32 GiB note: est. available: 30.47 GiB
        used: 12.66 GiB (41.6%)
      Processes: 504 Power: uptime: 1h 9m wakeups: 0 Init: systemd v: 255
        target: graphical (5) default: graphical
      Packages: 42 pm: flatpak pkgs: 33 pm: snap pkgs: 9 Compilers: clang: 17
        gcc: 14.1.1 Shell: pwsh running-in: script inxi: 3.3.34


My / drive is 23% full:

[quote=“{third: "Beedell", first: "Roke"}{.JSON5}, post:3, topic:124638, username:rokejulianlockhart”]
I’ve upgraded my packages many times. Usually every night, for approximately 4 months.
[/quote]

What we need to know is whether F40 was a fresh install or upgraded from an earlier version like F39, and whether the issue was present on F39. There are probes for Intel Wi-Fi 6E AX210/AX1675 wifi hardware in the LHDB, but just one for your motherboard. Your “sub-vendor” is Rivet Networks. Intel docs often refer you to the sub-vendor to resolve issues, but Intel bought Rivit in 2020, so you should be able to get help directly from Intel.

Quoting Intel Community:

Please file a new case so that we can properly support you.

Intel Support: https://www.intel.com/content/www/us/en/support.html

By the way, I'm truly sorry, it should be Intel® System Support Utility for the Linux* Operating System.
1 Like

@gnwiii:

It’s only ever been a Fedora 40 KDE Spin installation. I was using openSUSE TW at the time of F39.

Thanks. I’ll contact https://www.intel.com/content/www/us/en/support.html if TP-link and ASRock aren’t of any use, since the PCIe card - https://www.amazon.co.uk/gp/product/B09VPQ6NP6/ref=ppx_yo_dt_b_search_asin_title?ie=UTF8&psc=1, which appears to be a rebrand of the Archer AXE5400 - is sold by TP-Link, and per HW probe of ASRock X670E Taichi Desktop Computer #3641e3c6d3, my motherboard is an ASRock 670E Taichi.
